DEBRIS HOPPER
Capacity 4.35 cubic yards / 3.32 cubic meters
Construction Aluminum (Stainless Steel optional)
Exterior Finish Vinyl Wrap
Interior Finish Aluminum (Stainless Steel optional)
Suction Tube Diameter 10 inch
Suction Tube Material Replaceable, Polyethylene
Engine Shroud (optional) Stainless Steel
Inspection Doors 1 on each side
Inspection Door Opening 13.7 inch x 26 inch
Dump Type Hydraulic low dump to rear
Dump Type Hydraulic
Dump Height 70 inch
Dump Controls Electric In-cab
Separator Screen Construction 2 pc Stainless Steel
Separator Screen Maintenance Hydraulic assist access door
HYDRAULIC SYSTEM
Gauges Heads up LCD display
Reservoir Capacity 36 Gallons
Main Pump Pressure compensated piston
Gallons Per Minute (GPM) 8 gpm
Fan Motor Fixed displacement gear
Dump Cylinders (2) 4 inch x 16 inch
Head Cylinders (2) 1.5 inch x 6.5 inch
Broom Cylinder 2 inch x 4 inch
Hoods Up Cylinder 1.5 inch x 6.5 inch
Dump Door Cylinder (2) 1.5 inch x 6.5 inch
Filter (High Pressure) Cartridge
Filter (Low Pressure) Spin-on
Protection Low oil, high temperature, overspeed shutdown
Hydraulic Fluid Grade AW 46
Fluid Gauge Sight gauge with temperature
Cooling DC forced air oil cooler
IMPELLER
Diameter 26 inch
Type 10 blade backward inclined high pressure
Drive Multi-groove banded belt
Construction 2 abrasion-resisting grades of keyed welded steel
Mounting 2 sealed & relubable ball bearings
Housing Construction Welded steel
Housing Type Unobstructed for open airflow
Liner Replaceable corded rubber
Liner Bolts Coated for increased abrasion resistance
DUST SUPPRESSION
Water Capacity 105 gallons
Tank Construction Polyethylene
Pump Type 12 volt, Diaphragm
Controls In-cab
CURB BROOM
Controls Electric in-cab
Diameter 39 inches
Drive Direct - Hydraulic motor
Tilt Electric in-cab
Suspension Spring
Bristle Type Vertical digger
Bristle Material Oil tempered steel wire
Bristle Length 26 inches
SWEEPING HOOD
Type Blast - Suction / Right to Left
Towing Type 2 Trailing arms
Suspension 4 Springs
Up Storage Rubber stops
Type 2 piece
Material Welded steel
Pressure Tube 10 inch diameter AR steel
Suction Tube 10 inch diameter AR steel
Hood Widths Standard 82 inches, Optional 90 inches
Flaps 3 Total
Skids Single row reversible
Skid Material Steel with virgin Tungsten Carbide
“HOODS UP” (Anti-plowing) Independent hydraulics
“HOODS UP” Controls Electric in-cab
CONTROLS
Type Electric
Location In-cab
Circuit Breakers Individually resettable
Switches Rocker
STANDARD CHASSIS -
Make Isuzu
Model NPR Gas
Capacity / GVWR 12,000 lbs
PROPULSION ENGINE
Type/Fuel 4 Cycle / Gas
Model GMPT L8T (Gen V)
Cylinders 8
Displacement 6.6 L / 400 cid
Horsepower 350 hp @ 4,500 rpm
Starter 12v
Alternator 170 amp
Battery 12v - 750 CCA
Oil Filter Spin-on
Air Filter Dry-type
TRANSMISSION
Make 6L90 6-speed double overdrive
Type Automatic
Speeds 6 Forward, 1 Reverse
TIRES AND WHEELS
Configuration 2 Front, 4 Rear
Tire Type Tubeless / Steel belted radials
Tire Size 215/85R16E
Wheels Steel disc / One piece
BRAKES -
Type Front disc / Rear drum
Power Vacuum/Hydraulic with 4-channel ABS
Parking Mechanical / Transmission mounted
CAB
Type Cab over Engine
Engine Access Manual tilt
Construction Steel
Air Conditioning Standard
Radio Standard
Windows Electric
Door Locks Electric with remote
Steering Integral Power
WEIGHTS AND DIMENSIONS
Chassis GVWR 12,000 lbs
Chassis Only Curb Weight 5,204 lbs
Wheel Base 109 inches
Turning Diameter 33 ft 6 inches
Overall Length 214 inches
Overall Height 92 inches
Overall Width 92 inches
Sweeping Width (hood only) 90 inches
Sweeping Width (hood + left broom) 101 inches
Sweeping Width (hood + dual brooms) 116 inches
