DEBRIS HOPPER
Capacity 3.1 cubic yards
Construction Stainless Steel
Exterior Finish Vinyl Wrap
Suction Tube Diameter 10"
Suction Tube Material Replaceable, Polyethylene
Inspection Doors 2 (1 on each side)
Dump Type Hydraulic
Dump Cylinders 2 @ 3" x 10"
Dump Height 72"
Dump Controls Electric In-cab
Separator Screen Construction Stainless Steel
Separator Screen Maintenance Hydraulic access door
AUXILIARY ENGINE
Type/fuel 4 Cycle / Gas
Make Rehlko (formerly Kohler)
Model ECH740 / ECH749 Air Cooled
Number of Cylinders 2 OHV V-Twin
Displacement 747 cc
Bore 3.27 in
Stroke 2.72 in
Brake Horsepower 25/26.5 BHP
Oil Filter Spin-on
Air Filter 2 pc / Dry type w/ safety element
Fuel Gasoline - Electronic Fuel Injection
IMPELLER
Diameter 26"
Type 10 blade backward inclined high pressure
Drive Multi-groove banded belt
Construction 2 Abrasion resisting grades of injection molded steel
Mounting 2 Sealed & relubricable ball bearings
Housing Construction Welded steel
Housing Type Unobstructed for open airflow
Liner Replaceable, coated rubber
Liner Bolts Coated for increased abrasion resistance
HYDRAULIC SYSTEM
Pump Type Fixed displacement gear
Drive Belt
System Filtration 10 micron
Reservoir Capacity 10 gallons
Hydraulic Back-up System (optional)
Pump Type 12 volt DC
Controls In cab
Purpose Powers all hydraulic functions without auxiliary engine
DUST SUPPRESSION
Water Capacity 50 gallons
Tank Construction Aluminum
Pump Type 12 volt, Diaphragm
Controls In cab
CURB BROOM
Controls Electric in-cab
Diameter 26"
Drive Direct - Hydraulic motor
Tilt In-cab Electric
Suspension Torque sensing spring
Bristle Type Vertical digger
Bristle Material Oil tempered steel wire
Bristle Length 26"
SWEEPING HOOD
Type Blast - Suction / Right to Left
Towing Type 2 Trailing arms
Suspension 4 Springs
Up Storage Rubber stops
Material Welded steel
Pressure Tube 10" Diameter AR steel
Suction Tube 10" Diameter AR steel
Hood Width 82"
Direction Forward and reverse
Skids Steel with virgin Tungsten Carbide
CONTROLS
Type Electric In-cab
Circuit Breakers Resettable
Switches Rocker
Monitoring Hour meter
CHASSIS FORD F250
Make/Model Ford F250
Capacity / GVWR 9,900 lbs
Wheelbase 142"
Type/Fuel 4 Cycle Gas w/34 gal capacity
Engine 6.8L EFI V8 405 hp 445 ft lbs @ 4,000 rpm
Transmission TorqShift-G 10-speed Automatic
Battery / Alternator 12v 750CCA / 190A
Oil Filter Spin-on
Air Filter Dry-type
Brakes 4-wheel ABS Disc
Tires / Wheels LT245/75R5-17E / 17" Steel
CHASSIS CHEVROLET C2500 HD
Make/Model Chevrolet Silverado 2500HD
Capacity / GVWR 10,000 lbs
Wheelbase 142"
Type/Fuel 4 Cycle / Gas w/36 gal capacity
Engine 6.6L EFI V8 401 hp 464 ft lbs @ 4,000 rpm
Transmission Allison 10-speed Automatic
Battery / Alternator 12v 720CCA / 170A
Oil Filter Spin-on
Air Filter Dry-type
Brakes 4-wheel ABS Disc
Tires / Wheels LT265/70R-17E / 17" Steel
>WEIGHTS AND DIMENSIONS
Total Empty Weight 8,500 lbs
Chassis Only Curb Weight 6,458 lbs
Wheel Base 142"
Turning Radius 24' 6"
Overall Length 232"
Overall Height 78"
Overall Width 82"
Sweeping Width (hood only) 80"
Sweeping Width (hood and left boom) 100"
Sweeping Width (hood and right broom) 100"
OPTIONAL EQUIPMENT
LED Hood Lights Back-up Alarm
Front Spray Bar Spare Tire & Wheel
LED Bar Light 12 volt Backup
HD Steel Intake Tube LH Gutter Broom
Hopper Drain Hand Hose 5"
Tool Boxes RH Gutter Broom
STANDARD 12 MONTH LIMITED WARRANTY
12 Month, 1,200 Hour Warranty (whichever occurs first)
1. Chassis - 3 yr / 36,000 miles bumper-to-bumper*
2. Chassis Powertrain - 5 yr / 60,000 miles*
3. Rehlko (formerly Kohler) Auxiliary Engine - Limited 36 months*
4. Sweeper Unit - Limited 12 months or 1200 hrs*
