Capacity 4.35 cubic yards/ 3.32 cubic meters
Construction Stainless Steel
Exterior Finish. Vinyl Wrap
Interior Finish Stainless Steel
Suction Tube Diameter 10”
Suction Tube Material Replaceable, Polyethylene
Engine Shroud (optional) Stainless Steel
Inspection Doors 1 on each side
Inspection Door Opening 13.7” x 26”
Dump Type Hydraulic
Dump Cylinders 2 @ 4” x 16”
Dump Height 70”
Dump Controls Electric In-cab
Separator Screen Construction 2 pc Stainless Steel
Separator Screen Maintenance Hydraulic assist access door
Type/fuel 4 Cycle / Turbo Aftercooled Diesel
Make Perkins
Model 404F-22TA
Number of Cylinders 4
Displacement 135 cu in/2.2 litres
Bore 3.3 in/85 mm
Stroke 3.9 in/100 mm
Brake Horsepower 67 BHP/50 KW
Oil Filter Spin on
Air Filter 2 pc / Dry type w/ safety element
Safety Shutdown Oil Pressure
Diameter 30”
Type 10 blade backward inclined high pressure
Drive 4 Groove banded belt
Construction 2 Abrasion resisting grades of keyed welded steel
Mounting 2 Sealed & relubable ball bearings
Housing Construction Welded steel
Housing Type Unobstructed for open airflow
Liner Replaceable corded rubber
Liner Bolts Coated for increased abrasion resistance
Pump Type Fixed displacement gear
Drive Direct
Pump Capacity 5 GPM
System Filtration 6 micron
Reservoir Capacity 13 gallons
Pump Type 12 volt DC
Controls In cab
Purpos Powers all hydraulic functions without auxiliary engine
Water Capacity 105 gallons
Tank Construction Polyethylene
Pump Type 12 volt, Diaphram
Controls In cab
Controls Electric in-cab
Diameter 39”
Drive Direct - Hydraulic motor
Tilt Electric in-cab
Suspension Spring
Bristle Type Vertical digger
Bristle Material Oil tempered steel wire
Bristle Length 26”
Type Blast - Suction / Right to Left
Towing Type 2 Trailing arms
Suspension 4 Springs
Up Storage Rubber stops
Type 2 piece
Material Welded steel
Pressure Tube 10” Diameter AR steel
Head Width Standard 82”, Optional 90”
Flaps 3 Total
Front 1/4” x 6.5” non-corded rubber
Middle 3/8” x 6” non-corded rubber
Rear 1/2”x 6” non-corded rubber
Skids Single row
Skid Material Steel with virgin Tungsten Carbide
“HEADS UP”’ (Anti-plowing) Independent hydraulics
“HEADS UP” Controls Electric in-cab
Type/Fuel 4 Cycle / Gas
Model GMPT L96 (Gen IV) V8 Vortec
Cylinders 8
Displacement 6.0 L / 365 cid
Horsepower 297 hp @ 4,300 rpm
Starter 12v
Alternator 145 amp
Battery 12v - 750 CCA
Oil Filter Spin-on
Air Filter Dry-type
Type Front disc / Rear drum
Power Vacuum/Hydraulic with 4-channel ABS
Parking Mechanical / Trans mounted
Type Cab over EngineCab over Engine
Engine Access Manual tilt
Construction Steel
Air Conditioning Standard
Radio Standard
Windows Electric
Door Locks Electric
Steering Integral Power
Total Empty Weight 9,900 lbs
Chassis Only Curb Weight 5,326 lbs
Wheel Base 109”
Turning Diameter 33’ 6”
Overall Length 214”
Overall Height 92”
Overall Width 92”
Sweeping Width (hood only) 82” or 90”
Sweeping Width (hood and left broom) 101”
Sweeping Width (hood and dual brooms) 116”
